This window makes available the operations on the types of photo defined in Defining the types of photo.
For each type of photo, it is possible to acquire a photo of the patient positioned on a device (for instance, the posture analyzer), and then perform some operations on the photo acquired.
Photos acquired and to acquire
The buttons shown in this window assume one of two styles to indicate if the photo has been acquired or has not yet been acquired:
Available operations
A menu with the available operations will appear when clicking the button of a type of photo.
The operations displayed in the menu can be enabled and made visible according to the status of the photo acquired.
These operations are detailed here below.
Acquire a photo
Calls up the photo acquisition window.
The menu item is visible only when the photo has not been acquired yet.
Acquire the photo overwriting the existing
Calls up the photo acquisition window and overwrites the photo already acquired.
The menu item is visible only when the photo has been acquired.
View / measure photo
Calls up the Operations and measurements on the photos window.
The menu item is visible only when the photo has been acquired.
Save photo to file
Allows saving the acquired photo to a file in a folder chosen by the user.
The menu item is visible only when the photo has been acquired.
Load photo from file
Allows loading a photo from a file.
If the photo has already been acquired, the overwriting is confirmed by a message.
View information
Views some technical information about the photo acquired and the acquisition device.
Delete photo
Deletes the photo acquired.
The menu item is visible only when the photo has been acquired.
Exit
Exits the operations menu
